UPSOLAR M230P Solar module Polycrystalline Warranty 10 years 90% and 25 years 80% STC Power Rating Pmp (W) 230 Wp Voltage at Maximim Power Vmp (V) (Vmpp) 29,94 V Current at Maximim Power Imp (A) 7,68 A Open Circuit Voltage Voc (V) 36,9 V Short Circuit Current Isc (A) 8,27 A ... (Read the full Tiiip)

7 pts from Harrier2

Evaluate

Where is this found?

"Descrizione" about UPSOLAR M230P Review Consensus 7
by Harrier2 (1070 pt)

2019-Dec-07 19:45

UPSOLAR M230P Solar module Polycrystalline Warranty 10 years 90% and 25 years 80% STC Power Rating Pmp (W) 230 Wp Voltage at Maximim Power Vmp (V) (V ...

Read the full Tiiip

(Send your comment)

Read other Tiiips about this object in __Italiano (1)

Last update: 2019-12-07 19:17:21

About Us Terms of use FAQ Invite a Friend Contact Us Language (en)

Select Language

English

Italiano


Donate	App	Join	Log in


Donate	App	Join	Log in


Warranty	10 years 90% and 25 years 80%
STC Power Rating Pmp (W)	230 Wp
Voltage at Maximim Power Vmp (V) (Vmpp)	29,94 V
Current at Maximim Power Imp (A)	7,68 A
Open Circuit Voltage Voc (V)	36,9 V
Short Circuit Current Isc (A)	8,27 A
Power Tolerance (+)	+ 3 %
Power Tolerance (-)	- 3 %
Temperature	47±2 °C
Operating Temperature	-40~85 °C
Temperature Coefficiency Pmax	-0,47 %/°C
Temperature Coefficiency Voc	-0,346 %/°C
Temperature Coefficiency Isc	0,036 %/°C
Maximum System Voltage Vmax (V)	1000 V
Nominal Fuse Voltage	10 A
Sizes	1640x992x45 mm
Weight	19 kg
Cell Type	Polycrystalline
Cells	60
Glass type	Tempered
Glass Thickness	3,2 mm
Frame Type	Aluminium Alloy Anodized
Plug Connector safety	IP 65
Cables Section	4 mm²
Cable Length	900 mm
