Compendium of the most significant studies with reference to properties, intake, effects.
Ritters L, Tian Y, Reichl S. Spray-Dried Paracetamol/Polyvinylpyrrolidone Amorphous Solid Dispersions: Part I-Stability of Powders and Tablets. Pharmaceutics. 2021 Nov 16;13(11):1938. doi: 10.3390/pharmaceutics13111938.
Abstract. The formulation of active pharmaceutical ingredients (APIs) in amorphous solid dispersions (ASDs) is a promising approach to improve the bioavailability of poorly soluble compounds. However, problems often arise in the production of tablets from ASDs regarding the compressibility and recrystallization of the API. In the present study, the preparation of spray-dried ASDs of paracetamol (PCM) and four different types of polyvinylpyrrolidone (PVP) and their further processing into tablets were investigated.
Knopp MM, Nguyen JH, Mu H, Langguth P, Rades T, Holm R. Influence of Copolymer Composition on In Vitro and In Vivo Performance of Celecoxib-PVP/VA Amorphous Solid Dispersions. AAPS J. 2016 Mar;18(2):416-23. doi: 10.1208/s12248-016-9865-6.
Abstract. Previous studies suggested that an amorphous solid dispersion with a copolymer consisting of both hydrophobic and hydrophilic monomers could improve the dissolution profile of a poorly water-soluble drug compared to the crystalline form. Therefore, this study investigated the influence of the copolymer composition of polyvinylpyrrolidone/vinyl acetate (PVP/VA) on the non-sink in vitro dissolution behavior and in vivo performance of celecoxib (CCX) amorphous solid dispersions.
Wlodarski K, Sawicki W, Kozyra A, Tajber L. Physical stability of solid dispersions with respect to thermodynamic solubility of tadalafil in PVP-VA. Eur J Pharm Biopharm. 2015 Oct;96:237-46. doi: 10.1016/j.ejpb.2015.07.026.
Abstract. The aim of this paper was to evaluate physical stability of solid dispersions in respect to the drug, tadalafil (Td), in vinylpyrrolidone and vinyl acetate block copolymer (PVP-VA)....Copyright © 2015 Elsevier B.V.
Qiang W, Löbmann K, Knopp MM, McCoy CP, Andrews GP, Zhao M. Investigation into the role of the polymer in enhancing microwave-induced in situ amorphization. Int J Pharm. 2021 Nov 20;609:121157. doi: 10.1016/j.ijpharm.2021.121157.
Abstract. Microwave-induced in situ amorphization is an emerging technology to tackle the persistent stability issue of amorphous solid dispersions (ASDs) during manufacture and storage. The aim of this study was to introduce new effective polymeric carriers with diverse properties to microwave-induced in situ amorphization and to better understand their functions in relation to the final dissolution performance of microwaved tablets. ...Copyright © 2021 Elsevier B.V.
Kirubakaran P, Wang K, Rosbottom I, Cross RBM, Li M. Understanding the Effects of a Polymer on the Surface Dissolution of Pharmaceutical Cocrystals Using Combined Experimental and Molecular Dynamics Simulation Approaches. Mol Pharm. 2020 Feb 3;17(2):517-529. doi: 10.1021/acs.molpharmaceut.9b00955.
Abstract. The molecular interactions between the surfaces of cocrystals [i.e., flufenamic acid and theophylline (FFA-TP), flufenamic acid and nicotinamide (FFA-NIC), and carbamazepine and nicotinamide (CBZ-NIC)] and the polymers [i.e., polyethylene glycol (PEG), polyvinylpyrrolidone (PVP), and copolymer of vinylpyrrolidone (60%)/vinyl acetate (40%) (PVP-VA)] were investigated through combined experimental and molecular dynamics simulation approaches to resolve the mechanisms of cocrystal dissolution and precipitation. It was found that adsorption of the polymers on the surfaces of cocrystals might prevent the precipitation of the parent drug and alter the dissolution rate. The effect of polymers on precipitation could be determined by the cocrystal dissolution rate, the interactions of polymers with the surfaces of cocrystals, the characters of the noncovalent bonds formed between the polymers and the cocrystal surfaces, and the mobility and conformation of the polymers. The etching experiments of single cocrystals revealed that FFA-NIC and CBZ-NIC appeared as surface precipitation cocrystals while FFA-TP could lead to bulk precipitation. Both PVP and PVP-VA were good precipitation inhibitors for FFA-NIC, and they could completely inhibit the recrystallization of FFA III on the surfaces of dissolving cocrystals. In addition, as the adsorption of the polymer was slower than dissolution rate of the cocrystals, PVP and PVP-VA could only partially inhibit the recrystallization of CBZ dihydrate on the surface of CBZ-NIC. While PEG had no inhibitory effect on the surface crystallization of FFA-NIC and CBZ-NIC, due to its weak interactions with the surfaces of the cocrystals, it enhanced the dissolution performance of FFA-TP. In contrast, PVP and PVP-VA reduced the dissolution rate of FFA-TP and subsequently undermined the performance of cocrystals. Taken together, the approach of combining experimental and molecular dynamics simulation provided insights into the mechanisms of cocrystal dissolution as well as the polymers acting as inhibitory excipients for precipitation/recrystallization, making contribution to the development of novel formulations.
Guo M, Wang K, Hamill N, Lorimer K, Li M. Investigating the Influence of Polymers on Supersaturated Flufenamic Acid Cocrystal Solutions. Mol Pharm. 2016 Sep 6;13(9):3292-307. doi: 10.1021/acs.molpharmaceut.6b00612.
Abstract. The development of enabling formulations is a key stage when demonstrating the effectiveness of pharmaceutical cocrystals to maximize the oral bioavailability for poorly water soluble drugs. Inhibition of drug crystallization from a supersaturated cocrystal solution through a fundamental understanding of the nucleation and crystal growth is important. In this study, the influence of the three polymers of polyethylene glycol (PEG), polyvinylpyrrolidone (PVP), and a copolymer of N-vinly-2-pyrrodidone (60%) and vinyl acetate (40%) (PVP-VA) on the flufenamic acid (FFA) crystallization from three different supersaturated solutions of the pure FFA and two cocrystals of FFA-NIC CO and FFA-TP CO has been investigated by measuring nucleation induction times and desupersaturation rates in the presence and absence of seed crystals. It was found that the competition of intermolecular hydrogen bonding among drug/coformer, drug/polymer, and coformer/polymer was a key factor responsible for maintaining supersaturation through nucleation inhibition and crystal growth modification in a cocrystal solution. The supersaturated cocrystal solutions with predissolved PEG demonstrated more effective stabilization in comparison to the pure FFA in the presence of the same polymer. In contrast, neither of the two cocrystal solutions, in the presence of PVP or PVP-VA, exhibited a better performance than the pure FFA with the same predissolved polymer. The study suggests that the selection of a polymeric excipient in a cocrystal formulation should not be solely dependent on the interplay of the parent drug and polymer without considering the coformer effects.
Be Rziņš KR, Fraser-Miller SJ, Walker GF, Rades T, Gordon KC. Investigation on Formulation Strategies to Mitigate Compression-Induced Destabilization in Supersaturated Celecoxib Amorphous Solid Dispersions. Mol Pharm. 2021 Oct 4;18(10):3882-3893. doi: 10.1021/acs.molpharmaceut.1c00540.
Abstract. Compression-induced destabilization was investigated in various celecoxib amorphous solid dispersions containing hydroxypropyl methylcellulose (HPMC), poly(vinylpyrrolidone)/vinyl acetate copolymer (PVP/VA), or poly(vinylpyrrolidone) (PVP) at a concentration range of 1-10% w/w. Pharmaceutically relevant (125 MPa pressure with a minimal dwell time) and extreme (500 MPa pressure with a 60 s dwell time) compression conditions were applied to these systems, and the changes in their physical stability were monitored retrospectively (i.e., in the supercooled state) using dynamic differential scanning calorimetry (DSC) and low-frequency Raman (LFR) measurements over a broad temperature range (-90 to 200 and -150 to 140 °C, respectively). Both techniques revealed similar changes in the crystallization behavior between samples, where the application of a higher compression force of 500 MPa resulted in a more pronounced destabilization effect that was progressively mitigated with increasing polymer content. However, other aspects such as more favorable intermolecular interactions did not appear to have any effect on reducing this undesirable effect. Additionally, for the first time, LFR spectroscopy was used as a viable technique to determine the secondary or local glass-transition temperature, Tg,β, a major indicator of the physical stability of neat amorphous pharmaceutical systems.
S'ari M, Blade H, Cosgrove S, Drummond-Brydson R, Hondow N, Hughes LP, Brown A. Characterization of Amorphous Solid Dispersions and Identification of Low Levels of Crystallinity by Transmission Electron Microscopy. Mol Pharm. 2021 May 3;18(5):1905-1919. doi: 10.1021/acs.molpharmaceut.0c00918.
Abstract. Amorphous solid dispersions (ASDs) are used to increase the solubility of oral medicines by kinetically stabilizing the more soluble amorphous phase of an active pharmaceutical ingredient with a suitable amorphous polymer. Low levels of a crystalline material in an ASD can negatively impact the desired dissolution properties of the drug. Characterization techniques such as powder X-ray diffraction (pXRD), differential scanning calorimetry (DSC), and Fourier transform infrared spectroscopy (FTIR) are often used to detect and measure any crystallinity within ASDs. These techniques are unable to detect or quantify very low levels because they have limits of detection typically in the order of 1-5%. Herein, an ASD of felodipine (FEL) and polyvinylpyrrolidone/vinyl acetate copolymer (PVP/VA) prepared via a hot melt extrusion (HME) in a mass ratio of 30:70 was characterized using a range of techniques. No signs of residual crystallinity were found by pXRD, DSC, or FTIR. However, transmission electron microscopy (TEM) did identify two areas containing crystals at the edges of milled particles from a total of 55 examined. Both crystalline areas contained Cl Kα X-ray peaks when measured by energy-dispersive X-ray spectroscopy, confirming the presence of FEL (due to the presence of Cl atoms in FEL and not in PVP/VA). Further analysis was carried out by TEM using conical dark field (DF) imaging of a HME ASD of 50:50 FEL-PVP/VA to provide insights into the recrystallization process that occurs at the edges of particles during accelerated ageing conditions in an atmosphere of 75% relative humidity. Multiple metastable polymorphs of recrystallized FEL could be identified by selected area electron diffraction (SAED), predominately form II and the more stable form I. Conical DF imaging was also successful in spatially resolving and sizing crystals. This work highlights the potential for TEM-based techniques to improve the limit of detection of crystallinity in ASDs, while also providing insights into transformation pathways by identifying the location, size, and form of any crystallization that might occur on storage. This opens up the possibility of providing an enhanced understanding of a drug product's stability and performance.
Polyvinylpyrrolidone-vinyl acetate copolymer
